43F-LCF158-E01
4.3-10 Female Connector for 1-5/8" Coaxial Cable, OMNI FIT™ , O-ring sealing
Rev : C | Rev date : 03 Feb 2021
OMNI FIT™ high performance connectors are designed for use with both CELLFLEX® (copper) and CELLFLEX® Lite (aluminium) cables. They are designed specifically to provide the highest quality connector-cable interface while simplifying and speeding up connector attachment. All RFS Technologies connectors are fully tested for mechanical and electrical compliance to industry specifications.
The 4.3-10 connector is an innovative, space-saving RF connection meeting all requirements even under the most severe environmental conditions and not relying on coupling nut torque. Sealing against outer conductor and jacket by means of the o-ring and 360° compression fit. Multifunctional, self-lubricating HighTech polymer assembly locks on cable corrugation, avoids electrochemical potential differences and compression-fits to the jacket.
FEATURES / BENEFITS
- Ultra high PIM performance i.e. reduced interference leading to high customer satisfaction
- Two-piece design i.e. visual inspection of interlocking leads to improved installation security
- OMNI FIT™ concept i.e. streamlined order management and reduced stock level
- Watertight sealing in mated and unmated condition, i.e. reduced efforts during installation and improved security during operation
- Tri metal alloy plating i.e. extreme resistance against corrosion even under hardest climatic and environmental circumstances
- Multi-thread (Tristart) design i.e. simplified and accelerated tightening process
- RoHS (EU) and CRoHS (China) compliant i.e. can be used on a global basis
General Specifications |
|---|
| Transmission Line Type | | Coaxial Cable | | Cable Size | | 1 5/8 | | Cable Type | | Foam Dielectric | Radiating | | Model Series | | LCF158-50A-Series | LCF158-50L-Series | | Connector Interface | | 4.3-10 | | Connector Type | | OMNI FIT™ PREMIUM Straight | | Sealing Method | | O-ring | | Gender | | Female |
|
Electrical Specifications |
|---|
| Nominal Impedance, ohms | Ohm | 50 | | 3rd Order IM Product @ 2x20 Watts | dBc | -163 ; typical -167 | | Maximum Frequency | GHz | 2.75 | | VSWR, Return Loss | VSWR (dB) | 0 < f ≤ 1.0 GHz: 1.02 (40)
1.0 < f ≤ 2.2 GHz: 1.03 (37)
2.2 < f ≤ 2.75 GHz: 1.06 (31) |
|
Mechanical Specifications |
|---|
| Plating Outer/Inner | | Trimetal/Silver | | Length | mm (in) | 95.4 (3.756) | | Outer Diameter | mm (in) | 62.8 (2.472) | | Inner Contact Attachment | | Spring Finger | | Outer Contact Attachment | | Spring Claw |
|
Accessories |
|---|
| Wrench size front | mm (in) | 60 | | Wrench size rear | mm (in) | 60 | | Poly Hook Spanner | mm (in) | PHS 60-90-5 Ø 60-90 (2.3-3.5) Pin 5 (0.2) |
|
Testing and Environmental |
|---|
| Waterproof Level | | IP68 |
|
