HA-FOPLUG-A-04
Field Installable FullAXS Compatible Connector

Distributor Stock
Talley 399 Buy
Rev : A | Rev date : 24 Feb 2022

Ideal for adapting HYBRIFLEX Hybrid or Fiber Only jumpers to equipment requiring a FullAXS compatible optical fiber interconnect. Easily installed over factory LC fiber termination and seals on fiber OD. Dust cap included to seal unused fiber terminations.

FEATURES / BENEFITS

  • Cost effective solution
  • IP67 rated


External Document Links

Notes

Technical features

Mechanical Specifications

MaterialPlastic Shell with Rubber Oring
Mating Cycles100
Dust CapYes

Testing and Environmental

Operation Temperature °C (°F)-40 to 85 (-40 to 185 )
Sealing ClassIP67
UV-ProtectionYes

F/O Cable Specifications

Supported Fiber TypeSingle or Multi Mode with 5mm OD
Mating FaceFullAXS Plug
StandardRoHS Compliant
