TRIM-ICA12-C02
Automated trimming tool, ICA, RCF, RCA & LCF 12 OMNI FIT Standard, Trim Series C02/C03

Distributor Stock
Windy City Wire 38 Buy
Talley 32 Buy
Rev : B | Rev date : 11 Jun 2024


This automated trimming tool is designed to prepare ICA12-50JPL*, RCA12-50JPL* plenum-rated air dielectric and RADIAFLEX® RCF12-50, CELLFLEX® LCF12-50 foam dielectric coaxial cables for attachment of OMNIFIT Standard C02 & C03 connectors.

FEATURES / BENEFITS

  • Precision cable preparation tool
    Always exact and repeatable trimming dimensions
  • Intuitive use of tool
    Easy and precise preparation of cables for connector installation
  • Long-lasting cutting blades
    Low maintenance costs
  • Battery drill drive compatible
    Increased preparation speed


TRIM-ICA12-C02

External Document Links

Notes

Technical features

Structure

Product LineCoaxial Cable Accessories
Product TypeTool
Transmission Line TypeICA12, RCA12, RCF12, LCF12
Coaxial Cable TypeAir Dielectric, Foam Dielectric
Cable Size1/2"
Type of ToolAutomated Cable Trimming Tool

Mechanical Specifications

Material

Aluminum

Diameter mm (in)40.8 (1.6)

Packaging Information

Package Quantity1
Weight per piece kg (lb)0.22 (0.49)
